MICROTAIL Fully Automatic Water Level Controller 20 Ampere Capacity with 3 Sensors Wired Sensor Security System
MICROTAIL Fully Automatic Water Level Controller 20 Ampere Capaci...more
All details
Features, description and more
Specifications
Description
Warranty
Manufacturer info
All details
Features, description and more
Specifications
Description
Warranty
Manufacturer info
Show More
In the Box
1 x Controller, 3 x Sensors
General
Brand
MICROTAIL
Model Number
Fully Automatic Water Level Controller 20 Ampere Capacity with 3 Sensors
Wired/Wireless
Wired
Number of Sensors
3
Brand Color
White
Display Type
NA
Audible Alarm
No
Installation Type
Manually
Detection Range
500 ft
Minimum Alarm Distance
1 m
Maximum Alarm Distance
500 m
Color
White
Display Indicator
LED
LED Indicators
Yes
Suitable For
water pumps
Key Features
auto, manual switch
Additional Features
Technology Used
Microcontroller Based
Remote Control
No
Dimensions
Width
5 cm
Height
7 cm
Depth
10 cm
Weight
400 g
Power Features
Power Requirement
230V AC
Power Consumption
As per pump rating
Battery Type
not included
Other Power Features
Contact capacity : 20 A
See more
Package contains: l.Fully automatic water level controller 2.Three sensor for overhead tank. Item specification: 1. Condition: unused and undamaged item that is fully operational and functions as intended. 2.Warranty: 1 year warranty 3.Warranty service: fully automatic water level controller for tank this model will automatically switch on and automatically switch off the motor. Has auto on and auto off operation. auto on occurs when the tank level is low. Auto off when tank is full. Suitable for motor pump upto 2 Hp operated by a normal on/off switch / MCB. also suitable for electronic starter. Has LED indications for motor on. also has high and low level indication to know the level of tank. . Corrosion free sensors. Has manual mode and auto mode functions. In auto mode, auto on and auto off operation occurs. in manual mode, the motor pump will be constantly running. this controller unit has a fully automatic function (manual on and auto off function). Just keep the controller in manual mode for the motor to get switched on and then change it to auto mode for automatic off. long life. Easy to install. Advanced embedded technology. features: 1.Elegant looks 2.No man power required to operate as fully automatic 3.Avoid overflow longer life no mechanical system 4.Saves electricity 5. Compact plastic (virgin) housing 6. Control overhead tank specifications: 1.Operating voltage 220-250 volts ac. 2.frequency 50 hz . 3.Load capacity each switch (2 Hp)
See more
Warranty Summary
For warranty process customer should send product back to our company via any courier service. One side courier charge will be applicable on customer only.
Covered in Warranty
Product Malfunctioning, Controlling issues
Not Covered in Warranty
Damage, Burnout, Warranty seal broken, Fired Product, Sensor is not under warranty.
Warranty Service Type
Repair
Generic Name
Sensor Security System
Country of Origin
India
Name and address of the Manufacturer
XCELLENT MICROTECH INDIA
Name and address of the Packer
XCELLENT MICROTECH INDIA
